Case CX210C - General Specification - Main Equipment

INTRODUCTION
Generalspecication-Mainequipment
Lowercomponent
Travelunit
ManufacturerKYBCorporation
MotortypeVariabledisplacementpistonmotor
Automatic2-speedswitchoverwithparkingbrake
Intakeamount
168.9cm³/rev(10.31in³/rev)
Operatingpressure34.3MPa(4975psi)
Operatingow210.6l/min(55.6346USgpm)
Braketorque
32700N·m(24118lbft)min.(includingreductiongear)
Reliefvalvesetpressure35.3MPa(5120psi)at40l/min(10.57USgpm)
Automatic2-speedswitchoverpressure
25.8MPa(3742psi)
Reductiongear
ReductiongeartypePlanetarygear2-stagereductiongear
Reductionratio43.246
Dryweight
263kg(579.816lb)
Take-uproller
Weight
96.4kg(212.5256lb)
Upperroller
Weight
17.8kg(39.2423lb)
Lowerroller
Weight
35.5kg(78.2641lb)
Recoilspring
ItemWeight
Quantity
Yoke
23.9kg(52.6905lb)
1
SemsBM16X500.5kg(1.1023lb)
4
Threadedrod
24.8kg(54.6746lb)
1
GrooveheightNM481.0kg(2.2046lb)
1
SPpin8x800.1kg(0.2205lb)
1
Recoilspring
67.1kg(147.9302lb)
1
Greasecylinderassembly28.4kg(62.6113lb)
1
SemsBM16X600.3kg(0.6614lb)
2
Assembly(total)147.9mm(5.8228in)
Mountinglengthofspring576mm(22.68in)
Shoe
WeightorQuantity
600grouser
1339kg(2951.990lb)
Link1set
Shoe
49
Bolt196
Nut196
700grouser
1550kg(3417.165lb)
Link1set
Shoe
49
Bolt196
Nut196
800grouser
1692kg(3730.221lb)
Link1set
Shoe
49
4806312827/10/2016
22
