INTRODUCTION
Overallheight(totopofboom)2970mm(116.929in)3190mm(125.591in)
Overallheight(totopofcab)2950mm(116.142in)2950mm(116.142in)
Overallheight(totopofguardrail)3120mm(122.835in)3120mm(122.835in)
Upperstructureoverallwidth
2770mm(109.055in)2770mm(109.055in)
Swing(rearend)radius2750mm(108.268in)2750mm(108.268in)
Clearanceheightunderupperstructure1040mm(40.945in)1040mm(40.945in)
Minimumgroundclearance440mm(17.323in)440mm(17.323in)
Wheelbase(Centertocenterofwheels)3660mm(144.094in)3660mm(144.094in)
Crawleroveralllength4470mm(175.984in)4470mm(175.984in)
Trackgauge2390mm(94.094in)2390mm(94.094in)
Undercarriageoverallwidth[with600mm
(23.622in)shoes]2990mm(117.717in)2990mm(117.717in)
Crawlertracksheight920mm(36.220in)920mm(36.220in)
Workingranges
[2.94m(9.646ft)]Arm[2.4m(7.8740ft)]Arm
Boomlength
5700mm(224.409in)5700mm(224.409in)
Bucketradius
1450mm(57.087in)1450mm(57.087in)
Bucketwristaction
177°175°
MaximumreachatGRP
9730mm(383.071in)9240mm(363.780in)
Maximumreach
9900mm(389.764in)9420mm(370.866in)
Max.diggingdepth
6650mm(261.811in)6110mm(240.551in)
Max.diggingheight
9610mm(378.346in)9410mm(370.472in)
Max.dumpingheight
6810mm(268.110in)6590mm(259.449in)
