INTRODUCTION
Autoair-conditioner
Raindeector
Sunvisor
TopguardOPGlevel1(inCABstructure)
Roll-overprotectivestructure(ROPS)
Operator'sseat
KAB865:Lowfrequencyairsuspensionwithairspringsanddoubleactinghydraulicdamper.
Withfollowingfeatures
ManualweightadjustmentBackrestangleadjustment
SeatheightadjustmentAdjustablepivotingarmrestslinkedtoconsoles
Adjustableheadrest
Retractableseatbelt
Others
Rearviewmirror(Cabside&Rightside)
Rear&Rightsideviewcamera
Undercarriage
Travelmotor
Variabledisplacementaxialpistonmotor
BrakeMechanicaldiscbrake
Hydraulicservicebrake
Brakevalve
Finaldrive
Planetarygearreduction
High
5.6km/h(3.480mph)(Automatictravelspeedshifting)
Travelspeeds
Low
3.4km/h(2.113mph)
Drawbarpull188kN(42264.081lb)
Numberofcarrierrollers(eachside)
2
Numberofcarrierrollers(eachside)
8
Numberofshoes(eachside)
49
Typeofshoe
Triplegrousershoe
Linkpitch190mm(7.480in)
Widthofshoe
600mm(23.622in)(S.T.D)
Grade-ability70%(35°)
Mass
Operatingmass21400kg(47178.924lb)
with2.94m(9.6457ft)Arm,0.9m³Bucket,600mm(23.622in)grousershoe,operator,lubricant,coolant
andfullfueltank
Shippingmass20200kg(44533.377lb)
Operatingmass-(operatormass[75kg(165.35lb)])+90%offuelmass+bucketmass[760kg
(1675.513lb)])
Counterweightmass4100kg(9038.953lb)
Groundpressure
0.044MPa(6.38220psi)
with2.94m(9.6457ft)Arm,0.9m³Bucket,600mm(23.622in)grousershoe
Diggingforce(with1.0m³Bucket)(ISO6015)
[2.94m(9.6457ft)]Arm[2.4m(7.8740ft)]Arm
Armdiggingforce103kN(23155.32lb)123kN(27651.50lb)
Withautopowerup110kN(24728.98lb)132kN(29674.78lb)
Bucketdiggingforce142kN(31922.87lb)142kN(31922.87lb)
Withautopowerup152kN(34170.96lb)152kN(34170.96lb)
Dimensions
[2.94m(9.6457ft)]Arm[2.4m(7.8740ft)]Arm
Overalllength(withoutattachment)4950mm(194.882in)4950mm(194.882in)
Overalllength(withattachment)9400mm(370.079in)9480mm(373.228in)
