Case CX210C - Dimension

INTRODUCTION
Dimension
Standardarm[2.94m(9.6457ft)]
NOTE:Numbersaresubjecttochangewithoutnoticeduetodesignchangeorotherreason.
Thediagramsgivevaluesthatincludetheshoelugheight“a”[26mm(1.024in)].
9CF74B311
b.
1040mm(40.945in)
e.
440mm(17.323in)
c.
2390mm(94.094in)
f.
1430mm(56.299in)
d.
600mm(23.622in)
g.
1340mm(52.756in)
4806312827/10/2016
31
