Case CX210C - Page 76

Engine-Engineandcrankcase
6.Useawrench[7mm]toloosenthehoseband(1)on
theradiator,andthendisconnecttheupperhose(2).
SMIL13CEX1230AB3
7.Useawrench[7mm]toloosenthehoseband(1)on
theradiator,andthendisconnectthelowerhose(2).
•
Usecapstocovertheradiatorandhosestoprevent
theentryofwater,dustordirt.
•
Beforeremovingtheradiatorhoses,completely
drainthecoolant.
SMIL13CEX1231AB4
8.Useawrench[13mm]toloosenthe2linebolts(1),
andthendisconnectthe2lines(2)and(3)fromthe
compressor.
•
Alwaysremovethelow-pressure(suctionside)line
(2)rst.
•
Installcapsorplugstothecompressorandlinesto
preventanyentryofwater,dustordirt.
3.Line(dischargeside)
SMIL13CEX1232AB5
9.Useawrench[8mm]toloosenthehoseband(1)on
theintercooler,andthendisconnectthehose(2).
•
Usecapstocoverthelineandhosetopreventthe
entryofwater,dustordirt.
SMIL13CEX1233AB6
4806312827/10/2016
10.1[10.001]/13
