Case CX210C - Page 78

Engine-Engineandcrankcase
14.Useawrenchtoremovethe1nut(1),andthenre-
movethestartermotorwiring(2).
SMIL13CEX1239AB11
15.Removethehoseband(1),andthendisconnectthe
fuelhose(2).
•
Installcapsorplugstotheengineandhosetopre-
ventanyentryofwater,dustordirt.
SMIL13CEX1240AB12
16.Removethehoseband(1),andthendisconnectthe
fuelhose(2).
•
Installcapsorplugstotheengineandhosestopre-
ventanyentryofwater,dustordirt.
SMIL13CEX1241AB13
17.Useawrench[13mm]toremovethe2bolts(1),and
thendisconnecttheconnectorbracket(2).
SMIL13CEX1242AB14
4806312827/10/2016
10.1[10.001]/15
