INTRODUCTION
Dimension(-A.92.A.30)
CX225SR
Machinettedwithmonoblocboom5.70m
CRPH04B001F001
Dippers1.90m2.40m3.00m
(A)
3.08m3.14m2.90m
(B)
2.97m
(C)
8.97m8.93m8.85m
(D)
6.74m6.70m6.62m
(E)
2.80m
(F)
1.40m
(G)
1.68m
(H)
4.46m
(I)
3.66m
(J)
2.39m
(K)
0.60m
(L)withtrackpads600mm
2.99m
(L)withtrackpads700mm
3.09m
(L)withtrackpads800mm
3.19m
(M)
0.46m
(N)
1.40m
9-40691102/12/2004
11
