INTRODUCTION
Weight(-A.92.A.40)
CX225SR
Weightofmachine
Conguration
Weight
Ground
pressure
Withtrackpads600mm,monoblocboom5.70m,dipper2.40m,760kg
backhoe,driverandfullfueltank
22700kg0.47bar
Weightofcomponents
Engine487kg
Hydraulicpump125kg
Attachmentcontrolvalve187kg
Swingmoto-reductiongear
223kg
Travelmoto-reductiongear250kg
Boomcylinder200kg
Dippercylinder257kg
Bucketcylinder151kg
Counterweight
5880kg
Cab
kg
Turntable244kg
Upperstructurewithequipment(counterweightandturntable)
11770kg
Hydraulicswivel27kg
Undercarriagewithequipment
EUROPE
7020kg
NA
7730kg
Machinewithoutequipment
EUROPE
18840kg
NA
19550kg
Attachment3870kg
Boomwithequipment2200kg
Dipperwithequipment3.00m910kg
Dipperwithoutequipment3.00m599kg
Radiatorandoil-coolerassembly55kg
Fueltank160kg
Hydraulicreservoir145kg
Idlerwheel82kg
Upperroller17kg
Lowerroller35kg
Tensionshockabsorber142kg
Track600mm1350kg
Track700mm1570kg
Track800mm1710kg
