INTRODUCTION
Torque(-A.90.A.10)
CX225SR
STANDARDTIGHTENINGTORQUE
Orderoftighteningnutsandcapscrews.
Tightenalternatelysothattorqueremainsuniform.CapscrewswhicharettedwithLoctite(lookfortracesofa
whiteresidueonthethreadafterremoval),mustbecleanedwithathinoilorasuitablesolvent,thendried.
AddtwoorthreedropsofLoctitetothecapscrewthread,thentthescrew.
CRIL03H012E011
Thenumbersinthediagramsrepresenttheorderoftightening.
Tighteningtorque
Wheretherearenospecialinstructions,tightencapnutsscrewstothetorquesgiveninthetablebelow.
Standardtorquesettingtable.
Designationofcapscrews
(dimensions)
M6M8M10M12M14M16M18M20
Spannerinmm
1013171922242730
Capscrew
Torquesettingin
Nm
6.919.639.258.898.1157.2196274
Wrenchinmm
5
681012141417
Sockethead
screw
Torquesettingin
Nm
8.821.642.178.4117.6176.4245343
9-40691102/12/2004
7
