INTRODUCTION
Torque–Boltandnut
•
Tightenalternatingbetweenleftandrightandtopandbottomsothatuniformtighteningforceisapplied.
LPIL12CX00005EA1
•
If
LOCTITE®wasusedonaremovedbolt(thereissomethingwhitestickingtotheboltwhenitisremoved),cleanthe
oldLOCTITE®offwithcleaninguid,drythebolt,thenapply2-3dropsofLOCTITE®tothethreadsectionofthebolt.
Torquetable
Boltnominal
diameter(size)
M6M8M10M12M14M16M18M20
Wrench10mm13mm17mm19mm22mm24mm27mm30mm
Hexagon
bolt
Tighten-
ingtorque
6.9N·m
(5.089lb
ft)
19.6N·m
(14.456lb
ft)
39.2N·m
(28.912lb
ft)
58.8N·m
(43.369lb
ft)
98.1N·m
(72.355lb
ft)
156.9N·
m(115.72
3lbft)
196.1N·
m(144.63
6lbft)
294.2N·
m(216.99
1lbft)
Wrench
5mm
6mm8mm10mm12mm14mm14mm17mm
Hexagon
socket
headbolt
Tighten-
ingtorque
8.8N·m
(6.491lb
ft)
21.6N·m
(15.931lb
ft)
42.1N·m
(31.051lb
ft)
78.5N·m
(57.899lb
ft)
117.7N·m
(86.811lb
ft)
176.5N·
m(130.18
0lbft)
245.2N·
m(180.85
0lbft)
343.2N·
m(253.13
1lbft)
4787701401/07/2015
9
