INTRODUCTION
Generalspecication–Mainequipment
Lowercomponent
Travelunit
ManufacturerKYBCorporation
MotortypeVariabledisplacementpistonmotor
Automatic2-speedswitchoverwithparkingbrake
Intakeamount
181.3cm³/rev(11.1in³/rev)
Operatingpressure34.3MPa(4975psi)
Operatingow234L/min(61.8163USgpm)
Braketorque
32700N·m(24118lbft)min.(includingreductiongear)
Reliefvalvesetpressure35.3MPa(5120psi)at40l/min(10.57USgpm)
Automatic2-speedswitchoverpressure
25.8MPa(3742psi)
Reductiongear
ReductiongeartypePlanetarygear2-stagereductiongear
Reductionratio43.246
Dryweight
271kg(597.453lb)
Take-uproller
Weight
99.3kg(218.9190lb)
Upperroller
Weight
17.8kg(39.2423lb)
Lowerroller
Weight
37.7kg(83.1143lb)
Recoilspring
ItemWeight
Quantity
Yoke
25.7kg(56.6588lb)
1
SemsBM16X500.5kg(1.1023lb)
4
Threadedrod
28.5kg(62.8317lb)
1
GrooveheightNM481.3kg(2.8660lb)
1
SPpin8x800.1kg(0.2205lb)
1
Recoilspring
69.9kg(154.1031lb)
1
Greasecylinderassembly32.8kg(72.3116lb)
1
SemsBM16X600.3kg(0.6614lb)
2
Assembly(total)160.9mm(6.3346in)
Mountinglengthofspring576mm(22.677in)
Shoe
WeightorQuantity
600grouser
1476kg(3254.023lb)
Link1set
Shoe
51
Bolt204
Nut204
800grouser
1776kg(3915.410lb)
Link1set
Shoe
51
Bolt204
Nut204
4787701401/07/2015
20
