Engine-Engineandcrankcase
7.Removethefanguard(1).
LPIL12CX03543BB3
8.Useawrench[7mm]toloosenthehoseband(1)on
theradiator,andthenremovetheupperhose(2).
SMIL13CEX3130AB4
9.Useawrench[7mm]toloosenthehoseband(1)on
theradiator,andthenremovethelowerhose(2).
•
Usecapstocovertheradiatorandhosestoprevent
anyentryofwater,dustordirt.
•
Beforeremovingtheradiatorhose,completelydrain
thecoolant.
SMIL13CEX3131AB5
4802442623/05/2016
10.1[10.001]/13
