Case CX37C - Special Torque Settings

INTRODUCTION
Torque-Specialtorquesettings
Component
Boltsize
Torquesetting
Enginemountingbolt(engine–bracket)
M12×1.75
96.3–155.9N·m(71–115lbft)
Enginemountingbolt(bracket-frame)
M10x1.5
54.2–81.3N·m(40–60lbft)
Radiatormountingboltandnut
M10×1.5
54.2–81.3N·m(40–60lbft)
Engine
Couplingmountingbolt
M10×1.5
64.4–110.0N·m(47.5–81.1lbft)
Mainpumpmountingbolt
M12×1.75
74.6–112.5N·m(55–83lbft)
Maincontrolvalvemountingbolt
M10x1.5
54.2–81.3N·m(40–60lbft)
Fueltankmountingbolt
M12×1.75
96.3–155.9N·m(71–115lbft)
Hydraulicoiltankmountingbolt
M12×1.75
96.3–155.9N·m(71–115lbft)
Turningjointmountingboltandnut
M10x1.5
54.2–81.3N·m(40–60lbft)
Hydraulic
system
Swingmotormountingbolt
M14x2.0
164.1–221N·m(121–163lbft)
Swingbearinguppermountingbolt
M12×1.75
110.8–150.1N·m(81.7–110.7lbft)
Swingbearinglowermountingbolt
M12×1.75
110.8–150.1N·m(81.7–110.7lbft)
Travelmotormountingbolt
M12×1.75
125.8–145.3N·m(92.8–107.2lbft)
Power
train
system
Sprocketmountingbolt
M12×1.75
108.9–132.5N·m(80.3–97.7lbft)
Carrierrollermountingboltandnut
M12×1.75
108.9–132.5N·m(80.3–97.7lbft)
Under-
carriage
Trackrollermountingbolt
M18×2.0
366.2–444.6N·m(270.1–327.9lbft)
Counterweightmountingbolt
M20x2.5
482.8–653.4N·m(356.1–481.9lbft)
Cabmountingbolt
M12×1.75
96.1–155.0N·m(70.9–114.3lbft)
Other
systems
Operator’sseatmountingbolt
M8×1.25
19.7–30.8N·m(14.5–22.7lbft)
