INTRODUCTION
Radiator
ManufacturerT.RADCO.,LTD.
Weight
215kg(473.994lb)
Oilcooler
Oilvolume48L(12.680USgal)
Weight
29.5kg(65.036lb)
Radiator
Coolantcapacity9.9L(2.615USgal)
Weight
35.5kg(78.264lb)
Aircooler
Capacity32.5L(8.586USgal)
Weight
6kg(13.228lb)
Fuelcooler
Capacity2.1L(0.555USgal)
Totalweight
700kg(1543.236lb)
Hydraulicdevice
Hydraulicpump
Manufacturer
KawasakiHeavyIndustries,Ltd.
Mainpump
PumptypeDoublevariabledisplacementpistonpump
Displacementcapacity
278cm³/rev(16.965in³/rev)x2
Rated
31.4MPa(4555psi)
Operating
pressure
Maximum
34.3MPa(4975.22psi)
Inputrevolutionspeed1850RPM
Maximumdischargeow514l/min(514.000USgpm)x2(atPd=
2.0MPa(290.1psi)1850RPM)507l/min
(507.000USgpm)x2(atPd=7.85MPa
(1138.6psi)1850RPM)
Pilotpump
Pumptype
Gearpump
Displacementcapacity
15cm³/rev(0.92in³/rev)
Operatingpressure4.4MPa(638.220psi)
Maximumdischargeow27.8L/min(7.344USgpm)(at1850RPM)
Hydraulicsimultaneousconstantoutput
control
Maximumowadjustmentcontrolthrough
externalcommands(negativecontrol)
Maximumowadjustmentcontrolthrough
externalcommandmilli-amp(negative
control,frontside)
Controlmethod
Settinghorsepoweradjustmentcontrol
throughexternalcommandmilli-amp
Dryweight
300kg(661.3868lb)
HydraulicDriveFanPump
ManufacturerKOMATSUZENOAH(EATON)
Pumptype
Gearpump
Displacementvolume43.7cm³/rev(2.667in³/rev)
Permissiblepeakpressure24.5MPa(3554psi)other
Maximumspeed3000RPM
Maximumdischargevolume
127.2l/min(127.200USgpm)at20.6MPa(2988.0psi)3000RPM
Oiltemperature40°C(104.0°F)
Intakenegativepressure
–0.02-0.10MPa(–2.9010-14.5050psi)
DirectionofrotationLeftrotation(viewfromshaftend)
InputshaftshapeSAEinvolutespline:13T-16/32DP
Operatingpressure17.8MPa(2581.890psi)
Operatingow79.3l/min(79.300USgpm)
