Case CX800B - General Specification - Main Equipment

INTRODUCTION
Generalspecication-Mainequipment
Lowercomponent
Travelunit
ManufacturerKYBCorporation
MotortypeVariabledisplacementpistonmotor
Automatic2-speedswitchoverwithparkingbrake
Intakeamount
337.2-228.6cm³/rev(20.58-13.95in³/rev)
Operatingpressure34.3MPa(4975psi)
Operatingow500l/min(500.0000USgpm)
Braketorque
922N·m(680.03lbft)min.
Reliefvalvesetpressure35.3MPa(5120psi)
Automatic2-speedswitchoverpressure
26.5MPa(3844psi)
Reductiongear
ReductiongeartypePlanetarygear2-stagereductiongear
Reductionratio91.974
Dryweight
1052kg(2319.263lb)
Take-uproller
Weight
537kg(1183.8823lb)
Upperroller
Weight
74.5kg(164.2444lb)
Lowerroller
Weight
187kg(412.2644lb)
Recoilspring
ItemWeight
Quantity
Specialbolt0.1kg(0.2205lb)
1
High-strengthBM20x140
3.3kg(7.2753lb)
8
High-strengthW20
0.2kg(0.4409lb)
8
Checkvalveassembly0.1kg(0.2205lb)
1
Recoilspring
662kg(1459.4602lb)
1
Greasecylinderassembly153.4kg(338.1891lb)
1
Assembly(total)819kg(1805.6lb)
Mountinglengthofspring1310mm(51.57in)
Shoe
WeightorQuantity
650grouser
4264kg(9400.511lb)
Link1set
Shoe
51
Bolt204
Nut204
750grouser
4640kg(10229.449lb)
Link1set
Shoe
51
Bolt204
Nut204
900grouser
5272kg(11622.770lb)
Link1set
Shoe
51
Bolt204
Nut204
4802029215/06/2016
21
