INTRODUCTION
Withautopowerup340kN(76435lb)
Bucketdiggingforce414kN(93071lb)
Withautopowerup452kN(101614lb)
Dimensions
2.98m(9.7769ft)Arm
Overalllength(withoutattachment)7460mm(293.701in)
Overalllength(withattachment)13230mm(520.866in)
Overallheight(withattachment)5030mm(198.031in)
Cabheight3580mm(140.945in)
Upperstructureoverallwidth(withoutcatwalks)3470mm(136.614in)
Upperstructureoverallwidth(withcatwalks)4250mm(167.323in)
Swing(rearend)radius4300mm(169.291in)
Clearanceheightunderupperstructure1590mm(62.598in)
Minimumgroundclearance
890mm(35.039in)
Wheelbase(Centertocenterofwheels)5070mm(199.606in)
Crawleroveralllength6360mm(250.394in)
Trackgauge(Extended)3450mm(135.827in)
Trackgauge(Retracted)2830mm(111.417in)
Undercarriageoverallwidth[with650mm(25.591in)
shoes](Extended)
4360mm(171.654in)
Undercarriageoverallwidth[with650mm(25.591in)
shoes](Retracted)
3740mm(147.244in)
Crawlertracksheight1500mm(59.055in)
Workingranges
2.98m(9.7769ft)Arm
Boomlength
7250mm(285.433in)
Bucketradius
2260mm(88.976in)
Bucketwristaction
162°
MaximumreachatGRP
10250mm(403.543in)
Maximumreach
12370mm(487.008in)
Max.diggingdepth
6940mm(273.228in)
Max.diggingheight
10170mm(400.394in)
Max.dumpingheight
7830mm(308.268in)
