INTRODUCTION
Operatorenvironment
Operator'scab
Smoothandroundshapedesigncab,fabricatedbypresswork
Safetyglassforallwindows
Shock-lesscabsuspensionby4-pointuidmounting
Slidingfrontwindowwithautolock
Built-intypefull-colorLCDmonitordisplay
Membraneswitchonmonitordisplay
Windshieldwiper&washer
AM/FMRadiowithauto-tuner
Floormat
Hingedskylight
Autoair-conditioner
Cagetypeheadguard
Roll-overprotectivestructure(ROPS)
TopguardOPGlevel2(inCABstructure)
Operator'sseat
KAB855:Lowfrequencymechanicalsuspensionwithhelicalspringsanddoubleactinghydraulicdamper
Withfollowingfeatures
ManualweightadjustmentBackrestangleadjustment
Seatheightandtiltadjustment
Adjustablepivotingarmrests
Adjustableheadrest
Retractableseatbelt
Others
Rearviewmirror(Cabside&Rightside)
Undercarriage
Hydraulicservicebrake
Brakevalve
Finaldrive
Planetarygearreduction
High
4.3km/h(2.7mph)(Automatictravelspeedshifting)
Travelspeeds
Low
3.0km/h(1.9mph)
DBP(Drawbarpull)502kN(112854lb)
Numberofcarrierrollers(eachside)
2
Numberoftrackrollers(eachside)
9
Numberofshoes(eachside)
51
Typeofshoe
Triplegrousershoe
Linkpitch260.35mm(10.250in)
Widthofshoe
650mm(25.591in)(S.T .D)
Grade-ability70%(35°)
Mass
Operatingmass83200kg(183424.6lb)
with2.98m(9.7769ft)HDArm,4.5m³Bucket,650mm(25.591in)grousershoe,operator,lubricant,
coolantandfullfueltank
Shippingmass77900kg(171740.1lb)
Operatingmass-(operatormass[75kg(165.35lb)]+90%offuelmass+bucketmass[4530kg
(9986.94lb)]
Counterweightmass12500kg(27558lb)
Groundpressure
0.114MPa(16.536psi)
with2.98m(9.7769ft)Arm,4.5m³Bucket,650mm(25.591in)grousershoe
Diggingforce(with4.5m³bucket)(ISO6015)
2.98m(9.7769ft)Arm
Armdiggingforce311kN(69916lb)
