Case CX800B - Main Equipment Specifications

INTRODUCTION
Finaldrive
Planetarygearreduction
TurntablebearingBallbearingtypewithinternalgear
Maximumswingspeed
6.4RPM
Swingtorque266500N·m(196560lbft)
CylindersNO.ofcylinders–boreXRoddiameterXStroke
Boom
2xØ200mm(7.874in)-Ø140mm(5.512in)-1893mm(74.528in)
Arm
1xØ215mm(8.465in)-Ø150mm(5.906in)-2175mm(85.630in)
Bucket
1xØ215mm(8.465in)-Ø150mm(5.906in)-1520mm(59.843in)
Coolingfandrivesystem
Pump1vanepump
Motor
Fixeddisplacementaxialpistonmotor
Filters
Suctionlter
105μm
Returnlter
6μm
Pilotlinelter
8μm
Hydrauliccontrols
Boom/Arm/Bucket/SwingPilotpressurecontrolsystem(ISOcontrolpattern)
Travel
Pilotpressurecontrolsystem
SP-mode
H-mode
Workmodeselect
Auto-mode
Travelmodeselect
2-speedtravel
Attachmentcushioncontrol
Hydrauliclock(gatelock,leftsidetiltconsole)
Fanreverserotationsystem
Electricalsystem
Enginecontrol
Dialtypethrottlecontrol
Onetouchidle/Autodeceleration/Autoidleshutdownsystem
Emergencystop
Monitorsystem
Messagedisplay(Caution,condition,etc.)
Workmodedisplay(SP ,H,Auto)
Machinecondition(Powerboost,etc.)
Alarmdisplayandbuzzer
Watertemperature
Hydraulicoiltemperature
Fuellevel
Diagnosissystem
Wireharness
Waterprooftypeconnector
Safety
Travelalarm
Doublehorn
Battery
2X12V140A·h/5HR
Lights
Upper
24V70WX1
Boom24V70WX2
Workinglight
Cab
24V70WX2
Operator'scabroom
24V70WX1
4802029215/06/2016
18
