Case ISM - Exploded View (*)

Engine-Engineandcrankcase
Engine-Explodedview
N4LDI-TA-45SL
N4LDI-TA-50SL
NHIL13ENG0016AA1
(1)DieselOxidationCatalyst(DOC)assembly(8)Waterpump
(2)Differentialpressuresensor(9)Cylinderblock
(3)Cylinderhead(10)Cylinderheadgasket
(4)Cylinderheadbolts(11)Temperaturesensor
(5)Exhaustmanifold(12)Blow-byrecirculationlter
(6)Turbocharger(13)Exhaustelbow
(7)Coolingfan/Fanpulley
4763229316/09/2014
10.1[10.001]/13
