Case ISM - Engine Compression Test Procedure

Engine-Engineandcrankcase
Engine-Compressiontest
N843LT-F-27
N843T-F-24
N844L-F-30
N844L-F-34
N844L-F-36SL
N844LT-F-45SL
Compressiontestisperformedthroughtheglowplugports.Thetestadaptertool(1),isequippedwithquickcoupler
endsforeasyinstallationofthehoseandgauge.
1.Removethetwopinconnectorfromthefuelinjection
pumpsolenoid.
2.Removetheglowplugelectricalwireandwireconnec-
torfromtopoftheglowplugs.RefertoColdstartaid
-Remove—Glowplug(55.202).
3.Removealloftheglowplugs.
SECT10C01PG17_11
NOTE:Besurealltheglowplugsareremovedbeforestartingthecompressiontests.
4.InstalltheadapterToolNo.FNH00120,hoseand
gaugeassemblyOEM1074(2),ineachportandcrank
theengineuntilpressurestabilizes.Thegaugeshould
read2944.1kPa(427psi)plusorminus344.7kPa
(50psi).
SECT10C01PG17_22
NOTE:Itmaybenecessarytoremovesomeinjectorfuellinestoinstalltheadaptertool.
NOTE:Thereshouldnotbemorethan344.7kPa(50psi)variationbetweenthecylinders.
5.Installtheglowplugsandelectricalconnections.Refer
toColdstartaid-Install—Glowplug(55.202).
4763229316/09/2014
10.1[10.001]/16
