Case JX70 - Engine Removal - System Disconnections; Hydraulic, Diesel, and Brake System Disconnections

10 SECTION 10 -- ENGINE -- CHAPTER 1
84176554 -- 03--2008
14. Dicconnect the pressure pipe connection (1) of
the lift pump.
12
15. Disconnect the delivery lines of both hydraulic lift
pump (1) and hydrostatic steering pump (2).
13
16. Detach the cab heating pipes (1) and (2).
14
17. Detach the cab air--conditioning pipes (1) and
(2).
15
