Case JX70 - Engine Removal - Electrical Connections; Disconnecting Electrical Components

SECTION 10 -- ENGINE -- CHAPTER 1 13
84176554 -- 03--2008
26. Remove the fusebox (1) from the bonnet
support.
24
27. Remove the electrical oil pressure switch (1).
25
28. Remove the electrical connections of coolant
temperature sender (1).
26
29. Remove the electrical connection of pump
cut--out solenoid sender (1) and hydrostatic
steering pump oil pressure switch (2).
27
