SECTION 2 - OPERATION
2-3
The control valve has a joystick--type control handle
located beside the operator’s seat. The lever is
connected to the hydraulic control valve via two
control cables.
0136
4
The joystick can be locked in neutral to prevent
inadvertent operation of the loader. Lock the joystick
by moving the tab on the front of the housing to the
right. Check that the joystick is locked by moving the
handle fore and aft and left and right. If the handle will
not lock consult your dealer.
0136-a
5
Alternative 2
The other method is to connect to the tractor rear
remote valves and use the separate control levers to
control the movements of the loader.
RH02G122
RI06G023
6
