SECTION 2 - OPERATION
2-5
Loader Float Position
Move the lever to the float position, 3, (does not apply
to E-command, electronic control valve) and release
the lever to lower the loader arm without any
downward pressure.
To cancel the float function, move the lever
backwards somewhat (out of the float position) and
release it.
0135b
3
10
Attachment Roll Back/Dump
Move the lever left, 4, to roll the attachment back.
Move the lever right, 5, to dump the attachment.
0135c
4
5
11
