INTRODUCTION
Brakes
Servicebrake
Wet,activesonallwheels.
Parkingbrake
Mechanicalbrakeatspringsactuation,activeontransmission.
Steering
Turningcirclediameter(with10.00-20twintyres)15m(49.21ft)
Powersteering
Model
OSPD60/185LS
Displacement60-185cm³/rev(3.66-11.29in³/rev)
Maximumsteeringpressure
190-200bar(2755.0-2900.0psi)
Shockvalveadjustment240-260bar(3480.0-3770.0psi)
Electricalsystem
Servicevoltage
24V
Batteries2x12V
Batteriesrating
100A·h
Alternator70A
Startermotor
4kW(5.44Hp)
Buckets
Width
WeightHeapedcapacity
SAEcapacity
Numberofteeth
600mm(23.6in)330kg(727.5lb)0.28m³(9.9ft³)0.32m³(11.3ft³)
3
750mm(29.5in)370kg(815.7lb)0.36m³(12.7ft³)0.43m³(15.2ft³)
3
900mm(35.4in)410kg(903.9lb)0.46m³(16.2ft³)0.54m³(19.1ft³)
3
1000mm(39.4in)440kg(970.0lb)0.52m³(18.4ft³)0.62m³(21.9ft³)
4
1100mm(43.3in)470kg(1036.2lb)0.58m³(20.5ft³)0.70m³(24.7ft³)
5
1200mm(47.2in)490kg(1080.3lb)0.65m³(23.0ft³)0.77m³(27.2ft³)
5
NOTE:Fortheotheravailablebucketmodelsaddresstodealer.
47500167A31/01/2013
38
