Consumables
Supplysummarizingchart
COMPONENTTOBEFILLED
QUAN-
TITY
AKCELA
MANUFACTURER
SPECIFICATIONS
INTERNATIONAL
SPECIFICATIONS
Engine
5.5-12.5
l(1.5-3.3
USgal)
No.1EngineOil
15W–40
MS1121
APICl4
ACEAE7
Swinggear
4.2l(1.1
USgal)
TransaxleFluid
80W–140
MS1317
APIGL4
SAE80W140
Radiator(1)
11l(2.9US
gal)
Premium
Organic
Antifreeze
-
ASTMD3306
Fueltank
190l(50.2
USgal)
--
EN590
Frontsteeringaxlebody
8.8l(2.3
USgal)
Rearrigidaxlebody
11.2l(3.0
USgal)
Fontsteeringandrearrigidaxlesnal
drive
2.4l(0.6
USgal)x4
TransaxleFluid
80W–140
MS1317
APIGL4
SAE80W-140
Rearrigidaxlegearbox
2.5l(0.7
USgal)
No.1EngineOil
15W–40
MS1121
APICl4
ACEAE7
Hydraulicoiltank(2)
87l(23.0
USgal)
AWHydraulic
Fluid68HV
MS1216
DIN51524HVLP68
ISOVG68
Airconditioning
820g+/-
50(28.9oz
+/-1.8)
--
R134a
Windscreenwasher
1.5l(0.4
USgal)
TUTELA
PROFESSIONAL
SC35
--
Grease—Ballbearing
13.5kg
(29.8lb)
MolyGrease
251HEP-M
NLGI2
Grease—Undercarriage
---
DIN51825—KLP2K
30
Grease—Attachment
-
PremiumEP-2
-
NLGI2
NOTE:(1)Coolingsystemtotalvolume:~22l(5.8USgal).Water11l(2.9USgal)/Antifreeze11l(2.9USgal).
NOTICE:(2)Hydraulicsystemtotalvolume:~230l(60.8USgal).Ifthemachinewaslledwithbiodegradable
hydraulicoilPANOLINHLPSYNTH46(option),takenotethatthisoilcannotbemixedwithmineralhydraulicoil.
AddhydraulicadditiveforPanolin:3l(0.8USgal)
Temperatureoperatingranges
AKCELA
Viscosity
Environmenttemperature
range
SAE15W-40-15°C-+40°C
EngineNo.1Engineoil
SAE10W-30-25°C-+25°C
Swinggear
TransaxleFluid
80W–140
SAE80W-140-25°C-+45°C
Hydraulicsystem
AWHydraulicFluid68
HV
ISOVG68-25°C-+45°C
