Case WX165 - Page 344

DATA AND TECHNICAL SPECIFICATIONS
8-3
OUTFIT WITH OFF-SET BOOM
G = tyres maximum width
O = machine maximum width
mm (in)
DipperABCDEFGH I LMNOPQRST
2000
(78.73)
2550
(100.39)
430
(16.92)
1230
(48.42)
1850
(72.83)
370
(14.5)
2805
(110.43)
2520
(99.21)
3050
(120.07)
3910
(153.93)
345
(13.58)
4404
(173.38)
930
(36.61)
2500
(98.42)
1070
(42.12)
7884
(310.39)
8024
(315.90)
1175
(46.25)
1010
(39.76)
2300
(90.55)
2550
(100.39)
430
(16.92)
1230
(48.42)
1850
(72.83)
370
(14.5)
2377
(93.58)
2520
(99.21)
3050
(120.07)
3910
(153.93)
345
(13.58)
4484
(176.53)
930
(36.61)
2500
(98.42)
1070
(42.12)
7964
(313.54)
8104
(319.05)
1175
(46.25)
1010
(39.76)
2600
(102.36)
2550
(100.39)
430
(16.92)
1230
(48.42)
1850
(72.83)
370
(14.5)
3340
(131.49)
2520
(99.21)
3050
(120.07)
3910
(153.93)
345
(13.58)
4430
(174.41)
930
(36.61)
2500
(98.42)
1070
(42.12)
7910
(311.41)
8050
(316.92)
1175
(46.25)
1010
(39.76)
Dipper (mm) (in)
Rear blade
(kg) (lb)
Rear stabilizers
(kg) (lb)
Front blade and rear
stabilizers (kg) (lb)
2000 (78.73) 14314 (31491) 14785 (32527) 15256 (33563)
2300 (90.55) 14364 (31601) 14835 (32637) 15306 (33673)
2600 (102.36) 14414 (31711) 14885 (32747) 15356 (33783)
