DATA AND TECHNICAL SPECIFICATIONS
8-13
Monoboom
Dipper mm in 2000 78.74 2300 90.55 2600 102.36
A Maximum loading height mm in 4800 188.98 4800 188.98 5000 196.85
C Maximum depth mm in 6000 236.22 6300 248.03 6600 259.84
F Maximum outreach mm in 7000 275.59 7200 283.46 7500 295.27
H Front swing radius mm in 2500 98.42 1400 55.12 2400 94.49
K Minimum loading height mm in 1600 62.99 1300 51.18 1000 39.37
19
