Rev. 03-2004 Part 1. Operation Manual PAGE 1-37
FrontLoad Bill Validator Series - Operation and Service Manual
LOCK INSTALLATION TO CASSETTE
In order to install the security locks into the Cassette, open the Cassette cover, remove the plastic lock
and plug, and follow the diagram shown below:
DIA22.2max
A=
11
16
"±
1
16
"
or
A=1
1
8
"±
1
16
"
12.7max
A
B
Adjust size B
with Washers
within 0.6875±0.01"
or 1.125±0.01"
To Next Page
