CashCode FrontLoad Series - POWER INTERFACE MODULE

page 1-20 Part 1. Operation Manual Rev. 03-2004
Bill Acceptor FL Series Service Manual
rebmuNtraP rewoP ecafretnI ledoM rotcennoCyromeMhcuoT
0171-PLF CDV21 )detalosi-otpO(PDBLF-CC A oN
0172-PLF CDV21 )C232SR(TENCC,SPDB-CC A oN
0182-PLF CDV21 LPI-CC )tnerruCwoLesluPdetalosI( A oN
0175-PLF CDV42 )C232SR(TENCC,22CPG-CC B oN
The Power Interface Module offers the following options:
1) Input power: 12 VDC or 24 VDC;
2) Interface (see chart below for complete list of interfaces);
3) Model: reflects type of electronics within (A – with linear voltage regulation, B – with switching
voltage regulation). Model B provides higher power and must be used when additional modules are
included in the FrontLoad Bill Validator (e.g. Smart Card Reader)
4) Connector for Cassette Touch Memory (Dallas Chip) – a system which helps manage cash flow
and collects statistics from the Bill Validator.
POWER INTERFACE MODULE
