CashCode FrontLoad Series - HOUSING OPTIONS

Rev. 03-2004 Part 1. Operation Manual PAGE 1-21
FrontLoad Bill Validator Series - Operation and Service Manual
MODULAR
SYSTEM
rebmuNtraP
ettessaC
ezis
tekcarB
ytiruceslanoitpO
sehctiws
srotcennoC
0110-HLF 006 nialP enoN dradnatS
0140-HLF 006 elbakcoL enoN 9BD+EAJ
0150-HLF 006 nialP enoN 9BD+EAJ
0180-HLF 006 elbakcoL enoN dradnatS
0113-HLF 0001 nialP enoN dradnatS
0143-HLF 0001 elbakcoL enoN 9BD+EAJ
0153-HLF 0001 elbakcoL enoN dradnatS
0102-HLF 0001 nialP enoN 9BD+EAJ
The following combination of features described above are available:
Housing offers the following options:
1) Size of supporting bracket: 2 sizes are available – 600 bill Cassettes and 1000 bill Cassettes;
2) Locking mechanism in supporting bracket: Lockable bracket and Plain bracket are available.
Locking mechanism can operate with a ¾” tubular lock.
3) Security switches. Housing is equipped with a “Cassette removal” security switch and, if the
Lockable bracket option was selected, with an “Open lock” security switch. Both switches have
Quick Connect terminals (0.110) and are rated for 5A at 250 VAC. Optionally, a second switch for the
Cassette, and a Switch for the Validating Head can be added.
4) Interface connectors: JAE 12 pin (standard), JAE + DB9 (use with Card Reader Bezel), JAE
+ USB.
HOUSING
Housing for 600
bill Cassette with
Locking mecha-
nism.
Housing for 1000
bill cassette
without Locking
mechanism.
