page 1-50 Part 1. Operation Manual Rev. 03-2004
Bill Acceptor FL Series Service Manual
TROUBLESHOOTING
CashCode’s FrontLoad Bill Validator is equipped with a self-diagnostic feature to aid in repair and
maintenance. When the power to the Bill Validator is turned ON, the Bill Validator begins its self-
diagnostic operation.
If the self-diagnostic test is passed, then the status light will turn green. If an error is detected, then
the status light on the front of the Bill Validator will blink red.
The number of times the red light flashes on the Bill Validator, is an indication of a specific problem or
malfunction. A detailed list of these errors and corrective action is provided in the Diagnostics section
to follow.
TROUBLE-
SHOOTING
Status light
