BEZELS
Several Bezel designs are available in order to make the
CashCode Bill Validator compatible with different door
styles. Normally, the Bill Validator is supplied with the
Standard CashCode Bezel. Each type of bezel is available
for different bill path widths (path width for the bezel and
Validating Head must be the same).
Standard CashCode Bezel. The status indication
light is provided.
Status light
CashCode Bezel with running lights. The status
light is combined with runway lights.
Runway lights
CashCode Bezel with runway lights and digital
display. In addition to runway lights, a digital display of
2 lines (16 characters each) is provided. Users are
able to create a custom message – in order to attract
or instruct customers.
Digital display
