— 44 —
PARTS LIST(200CR/PCR-360/PCR-365)
Item Code No. Parts Name Specification Version Q R
1. MAIN PCB BLOCK
6193 2818 Main PCB ass'y E245-1 E240333*1 Other countries 1 C
6193 2825 Main PCB ass'y E245-1 E240333*2 US-OSS 1 C
6193 3784 Main PCB ass'y E245-1 E240333B*3 US-WHC 1 C
6193 3791 Main PCB ass'y E245-1 E240333B*4 Canada-OSS 1 C
6193 3798 Main PCB ass'y E245-1 E240333B*5 Canada-WHC 1 C
IC4 2006 1249 LSI LC3564S70/85/10 1 A
IC7 2006 1585 LSI UPD78054GC-213-3B9 1 A
IC5 2105 1169 IC TC74HC373AP 1 A
IC2,3,9,10 2120 6741 Monolythic IC BA12004 4 A
IC1 2120 6823 Liner IC LM2575T-5.0/LB03 1 A
IC8 2120 7381 Reset IC S-80730AN-Z 1 A
Q6,8,10,12 2210 7309 Transistor 2SB1240V2-Q,R 4 B
Q2,3,18 2220 2456 Transistor 2SC945(K,P,Q,R)-T 3 B
Q19 2230 4135 Transistor 2SD1853-AA 1 B
Q15 2230 5328 Transistor 2SD1933 1 B
Q4 2240 5367 Digital Transistor DTD113ZS-TP-T 1 B
Q16 2250 1043 Transistor 2SB865-AE 1 B
Q17 2250 1323 Transistor 2SA933AS(QRS)TP 1 B
Q5,7,9,11 2250 1491 Digital transistor DTC114YSA-TP-T 4 B
Q1 2253 0399 Power transistor 2SD1276A 1 A
D2~5,24,25 2301 0089 Diode 1SR35-100A-T-82-T 6 C
D1,6,8,10~22 2301 0101 Diode 1S2473-T-77-T 16 C
ZD1 2310 5284 Zener diode RD13EB3-TN-T 1 C
D7 2310 9452 Schottky barrier diode RK-14V 1 C
ZD2 2315 1120 Zener diode RD5.6EB3-TN-T 1 C
D9 2315 3095 Schottky barrier diode RB721Q-40T-77 1 C
D26 2390 0882 Schottky barrier diode RB100AT-32 1 C
X1 2408 8261 Ceramic oscillator CST5.00MGW 1 C
X2 2520 3445 Crystal oscillator C-002RX(M90-76) 1 C
R4 Carbon film resistor R50XT-08J202 1 X
R55 Carbon film resistor CR-25-6.8KOHMJ-T 1 X
R5,54 Carbon film resistor CR-25-2.2KOHMJ-T 2 X
R60 Carbon film resistor CR-25-200OHMJ-T 1 X
R10,14,19,20, Carbon film resistor CR-25-100OHMJ-T 7 X
21,22,26,
R1,46 Carbon film resistor CR-25-560OHMJ-T 2 X
R31 Carbon film resistor CR-25-820OHMJ-T 1 X
R8,42,57 Carbon film resistor CR-25-1KOHMJ-T 3 X
R32 Carbon film resistor CR-25-2KOHMJ-T 1 X
R3,29,36 Carbon film resistor CR-25-3.9KOHMJ-T 3 X
R7,52,59 Carbon film resistor CR-25-4.7KOHMJ-T 3 X
R33 Carbon film resistor CR-25-8.2KOHMJ-T 1 X
R9,15,16,17, Carbon film resistor CR-25-10KOHMJ-T 10 X
R18,28,49,
R53,56,58
R11,12,13, Carbon film resistor CR-25-56KOHMJ-T 9 X
R27,37,38,
R40,43,44
R51 Carbon film resistor CR-25-100KOHMJ-T 1 X
R39 Carbon film resistor CR-25-330KOHMJ-T 1 X
R50 Carbon film resistor CR-25-1MOHMJ-T 1 X
R34 Carbon film resistor CR-25-20KOHM-J-T 1 X
PARTS LIST (200CR/PCR-360/PCR-365)
