ā 45 ā
Item Code No. Parts Name Specification Version Q R
R2 Carbon film resistor CR-25-1.2KOHM-J-T 1 X
R41 Carbon film resistor CR-25-5.6KOHMJ-T 1 X
R48 Metal film resistor CRH200-FH24-J-101 1 X
RA3 Module resistor MS5635F 1 X
RA1 Module resistor MS1038F 1 X
RA2 Module resistor MS1036F 1 X
C7,8,14,17, TF capacitor ECQ-V1H-104-JZ3 9 X
C18,22,23,24,
C26
C6 2807 3533 Electrolytic capacitor RE2-25V330MMA-T2 1 C
C5 2807 3540 Electrolytic capacitor RE2-25V331MMA-T2 1 C
C3 2807 3547 Electrolytic capacitor RE3-35V470MMA-T2 1 C
C25 2807 3554 Electrolytic capacitor RE2-35V221MMA-T2 1 C
C2 2807 3561 Electrolytic capacitor RE3-35V332M-T 1 C
C13,20 Ceramic capacitor RT-HE50TKYB102K-T 2 X
C12 Ceramic capacitor RT-HE40TKYB471K-T 1 X
C4,9,10,19 Ceramic capacitor RT-HE40TKYB101K-T 4 X
C21 Ceramic capacitor RT-HE12TKYB103K-T 1 X
C16 Ceramic capacitor RT-HE40TKCH150J-T 1 X
C15 Ceramic capacitor RT-HE40TKCH120J-T 1 X
CA1,2,4 Module capacitor CNB5X101K 3 X
C1 Mylar capacitor 50F2S683J 1 X
CA3 Module capacitor CNB7X101K 1 X
L1 Inductor OWA1419-681K 1 X
F1 3000 7196 Fuse 218002 Other countries 1 A
F1 3631 0329 Fuse 237002 US, Canada 1 A
F2 3631 0328 Fuse UL-TSCR-0.8A 1 A
F1 3640 2331 Fuse clip UF-0033 2 C
BZ1 3122 1589 Sounducer PKM22EPP-2002 1 C
CN9 3500 3371 Connector 2P IL-G-2P-S3T2-E 1 C
CN2 3500 5831 PCB connector 52045-2045 1 C
CN13 3500 5832 PCB connector 5229-22APB 1 C
CN11 3500 5846 Connector 53253-0210 1 C
CN12 3501 6244 Connector B2B-PH-K-S 1 C
CN1 3510 2680 Pin ass'y 2P 5277-02A 1 C
CN7 3540 5081 PCB connector 52045-2545 1 C
Heat sink OSH-1625-SP 1 X
PCB E245-1 (without components) E240345-1 1 X
2. UPPER CASE BLOCK
1 6247 8807 Screw 4X85 ZMC-3 1 X
2 5460 0021 Washer 4X9X0.8 ZMC-3 1 X
3 6220 2505 Display bush E310377-1 1 X
4 6247 6455 Upper case E245 E140123-1 1 X
5 6247 6462 Display window E140124-1 1 C
67 6221 3783 FFC joiner B E411354-2 1 A
3. MAIN DISPLAY BLOCK
2320 1365 LED HDSP-5621#S02 4 B
Carbon film resistor ERD25TJ121V 8 X
Carbon film resistor ERDS2TJ121V 7 X
3500 5833 PCB connector 52044-2045 1 C
3500 5834 Pin ass'y 9P 53254-0910 1 C
3500 5835 Pin ass'y 11P 53254-1110 1 C
4306 1004 PCB E240-E2 (without components) E311067A-1 1 C
To Next Page
