Casio 200cR Service Manual

— 46 —
Item Code No. Parts Name Specification Version Q R
4. CUSTOMER DISPLAY BLOCK
2320 1365 LED HDSP-5621#S02 4 B
Carbon film resistor ERD25TJ121V 8 X
Carbon film resistor ERDS2TJ121V 7 X
4306 1004 PCB E240-E2 (without components) E311067A-1 1 C
7 6191 0334 Connector ass'y E311301*1 1 B
8 6247 6469 Display case E245 E240325-1 1 C
9 6247 6476 Rear case E245 E240326-1 1 C
5. KEYBOARD BLOCK
10 6221 3988 L cap E210964-1 Other countries 6 C
10 6221 3988 L cap E210964-1 US 1 C
10 6221 3988 L cap E210964-1 Canada 11 C
11 6221 4025 S cap E311103-1 Other countries 16 C
11 6221 4025 S cap E311103-1 US 40 C
11 6221 4025 S cap E311103-1 Canada 20 C
12 6245 3530 Key contact rubber E411877-1 Other countries 34 C
12 6245 3530 Key contact rubber E411877-1 US 53 C
12 6245 3530 Key contact rubber E411877-1 Canada 43 C
13 6245 7250 S button E238-1 E311792-1 1 C
14 6245 7260 S button E238-2 E311792-2 1 C
15 6245 7270 S button E238-3 E311792-3 1 C
16 6245 7280 S button E238-4 E311792-4 1 C
17 6245 7290 S button E238-6 E311792-5 1 C
18 6245 7300 S button E238-7 E311792-6 1 C
19 6245 7310 S button E238-8 E311792-7 1 C
20 6245 7320 S button E238-9 E311792-8 1 C
21 6245 7330 S button E238-0 E311792-9 1 C
22 6245 7340 S button E238-. E311792-10 1 C
23 6245 7350 S button E238-00 E311792-11 1 C
24 6245 7360 5 button E238 E311116-4 1 C
25 6246 7768 L button E210963A-4 Other countries 6 C
25 6246 7768 L button E210963A-4 US 1 C
25 6246 7768 L button E210963A-4 Canada 11 C
26 6246 7810 S button E311101A-4 Other countries 28 C
26 6246 7810 S button E311101A-4 US 52 C
26 6246 7810 S button E311101A-4 Canada 32 C
28 6247 3830 Coil spring A E411104A-1 Other countries 6 B
28 6247 3830 Coil spring A E411104A-1 US 1 B
28 6247 3830 Coil spring A E411104A-1 Canada 11 B
29 6247 3837 Coil spring B E411104A-2 5 B
30 6247 6315 Keyboard frame E140119-1 1 X
31 6247 6343 Button filler 4S E311265-4 Other countries 1 C
32 6247 6350 Button filler 5S E311265-5 Other countries 2 C
33 6247 6357 FPC E245 E240323-1 1 A
34 6247 6364 Spacer E340397-1 1 A
35 6247 6371 Common sheet E340398-1 1 A
36 6247 6378 Keyboard chassis E340412-1 1 X
37 6247 6910 Plate sub ass'y E240347A*3 Other countries 1 X
37 6247 6896 Plate sub ass'y E240347A*1 US 1 X
37 6247 6903 Plate sub ass'y E240347A*2 Canada 1 X
38 6192 4970 Mode key switch ass'y E311944*1 1 C
39 6247 6399 Mode key plate E440374-1 Other countries 1 X
39 6247 6406 Mode key plate E440374-2 US-OSS, Canada-OSS 1 X
39 6247 6413 Mode key plate E440374-3 US-WHC, Canada-WHC 1 X
Screw 3X8 ZMC-3..... 6 X
