Casio CDP-130 - Page 33

CDP-130
– 31 –
1: CDP-130_BLACK_DI
2: CDP-130_BLACK_EU
3: CDP-130_BLACK_UK
4: CDP-130_BLACK_US
5: CDP-130_SILVER_DI
6: CDP-130_SILVER_EU
7: CDP-130_SILVER_UK
8: CDP-130_SILVER_US
12345678
Main PCB
N 1 10471890 PCB UNIT/MAIN TK-RJM511112*002 11111111AMDA1
CN19 10236624 CONNECTOR/USB UBR24-4K5G00 11111111C
D6,D7 10009218 DIODE 1SS400TE61 22222222X
IC5 10211950 IC NJM2068M-D(TE1) 11111111X
IC11 10137770 IC TC7S08FU(TE85L.F) 11111111X
N IC6 10398240 IC XC6402FV36PR-G 11111111X
L11 10193074 COIL DLW21HN181SQ2L 11111111X
Q7,Q8 69300298 TRANSISTOR 2SC4081T106R 22222222X
X1 10375016 RESONATOR 7V48080006 11111111X
Power & Amp PCB
N 2 10399370 PCB UNIT/POWER & AMP TK-RJM511113*001 11111111BPSA1
N D1,D2 10260786 DIODE 1N5822-C144 22222222X
IC3 10375029 IC LA5756-MDB-E 11111111X
IC2 10306512 IC TDA7297 11111111X
J5 10206815 JACK/DAMPER PEDAL JY-6314*01-030 11111111B
J2 10305218 JACK/PHONES JY-6316B*01-070 11111111B
J3 10334294 JACK/DC KM02022ABMP 11111111A
L2 10231919 COIL RB53-856396NP 11111111X
L3,L4,L6 10231920 COIL RB53-856397NP 33333333X
L5 10232457 COIL RII7-860400NP 11111111X
N VR1 10407265 VARIABLE RESISTOR F164KPD-1N-CASIO-4 11111111BMain volume
D3,D4 23901820 DIODE 1SS355TE-17 22222222X
IC1 10306415 IC BH3547F-E2 11111111X
Q4 69409403 TRANSISTOR 2SA1576AT106R 11111111X
Q1-Q3 69300298 TRANSISTOR 2SC4081T106R 33333333X
Q'ty
R RemarksN Item Code No. Parts Name Specification
