CDP-130
– 32 –
1: CDP-130_BLACK_DI
2: CDP-130_BLACK_EU
3: CDP-130_BLACK_UK
4: CDP-130_BLACK_US
5: CDP-130_SILVER_DI
6: CDP-130_SILVER_EU
7: CDP-130_SILVER_UK
8: CDP-130_SILVER_US
12345678
Q'ty
R RemarksN Item Code No. Parts Name Specification
Keyboard PCB
3 10399792 PCB UNIT/KEYBOARD TK-RJM511215*001 11111111C
KYA1/KYB1/KYC1
with Rubber contact
N D801-D827 10398230 DIODE DAN202UMTL 27 27 27 27 27 27 27 27 X
N D828-D861 10398230 DIODE DAN202UMTL 34 34 34 34 34 34 34 34 X
N D862-D888 10398230 DIODE DAN202UMTL 27 27 27 27 27 27 27 27 X
4 10195879 RUBBER CONTACT/AG RJM502920-001V02 77777777A
5 10195880 RUBBER CONTACT/GC RJM502921-001V02 11111111B
Keyboard Unit
6 10399791 KEYBOARD UNIT TK-RJM511279*001 11111111C
N 7 10363265 WHITE KEY/SA RJM502795-003V05 11111111X
N 8 10398222 WHITE KEY/B RJM502794-001V04 11111111A
N 9 10398223 WHITE KEY/CEGB RJM502862-001V04 77777777A
N 10 10398225 WHITE KEY/DFA RJM502863-001V04 77777777A
N 11 10363266 WHITE KEY/SC RJM502796-003V05 11111111X
N 12 10398220 BLACK KEY RJM502797-001V03 36 36 36 36 36 36 36 36 A
13 10341062 HAMMER UNIT/W1 TK-RJM509600*001 13 13 13 13 13 13 13 13 C
14 10341063 HAMMER UNIT/W2 TK-RJM509601*001 13 13 13 13 13 13 13 13 C
15 10341064 HAMMER UNIT/W3 TK-RJM509602*001 13 13 13 13 13 13 13 13 C
16 10341065 HAMMER UNIT/W4 TK-RJM509603*001 13 13 13 13 13 13 13 13 C
17 10341066 HAMMER UNIT/B1 TK-RJM509604*001 99999999C
18 10341067 HAMMER UNIT/B2 TK-RJM509605*001 99999999C
19 10341068 HAMMER UNIT/B3 TK-RJM509606*001 99999999C
20 10341069 HAMMER UNIT/B4 TK-RJM509607*001 99999999C
21 10336108 FLAT CABLE UL2896-30-265-MACP 11111111X
N 22 10398226 FELT/LOWER LIMIT/BLACK KEY RJM510067-002V02 11111111X
N 23 10398227 FELT/LOWER LIMIT/WHITE KEY RJM503562-002V02 11111111X
N 24 10398219 FELT/UPPER LIMIT/HAMMER RJM511203-001V01 11111111X
25 10399793 FELT/LOWER LIMIT/HAMMER TK-RJM507910*001 11111111X
26 10388000 PLATE RJM510952-001V01 11111111X
