— 30 —
Item Code No. Parts Name Specification Version Q R
RA2 Module resistor MS5635F 1 C
RA3,4 Module resistor MS5636F 2 C
RA1,5 Module resistor MS1038F 2 C
X2 2801 8932 Ceramic oscillator CST4.19MGW 1 A
C6 2807 2231 Electrolytic capacitor RE2-50V470M-T2 1 C
C9 2807 2238 Electrolytic capacitor RE2-50V010M-T2 1 C
C8 2807 2245 Electrolytic capacitor RE2-25V331M-T2 1 C
C2 2807 2252 Electrolytic capacitor RE2-35V102M 1 C
C1 2807 2259 Electrolytic capacitor RE3-50V332M 1 C
C21 Ceramic capacitor HE40TJCH120J 1 X
C13~18,32, Ceramic capacitor HE50TJYB102K 14 X
C34~40
C20 Ceramic capacitor HE40TJCH150J 1 X
C43 Ceramic capacitor HE80TJYB472K 1 X
C33 Ceramic capacitor HE40TJYB471K 1 X
C25 Ceramic capacitor HE40TJYB101K 1 X
C3,5,11,12,19 Ceramic capacitor HE12TJYB103K 13 X
C22~24,26~28
C31,42
C30,41 TF capacitor ECQ-V1H-104-JZW 2 X
C10,29,44 TF capacitor ECQ-B1H103KFW 3 X
C4 Mylar capacitor 50F2S563J 1 X
F1 3000 6559 Fuse 237 315 1 A
L1 3018 0854 Inductor MCDR1419-681K 1 X
BUZZER 3122 1589 Sounducer PKM22EPP-2002 1 C
CN5 3500 3355 Pin ass'y 3P IL-G-3P-S3T2-E 1 C
CN3 3500 5831 PCB connector 52045-2045 1 C
CN4 3500 7122 Pin ass'y 53253-0310 1 C
CN2 3501 5460 FFC connector 52045-2845 1 C
CN6 3501 5474 FFC connector 52045-2245 1 C
CN1 3510 2680 Pin ass'y 2P 5277-02A 1 C
F2 3631 0328 Fuse UL-TSCR-0.8A 1 A
F1 3640 2331 Fuse clip UF-0033 2 X
Heat sink OSH-1625-SPL 1 X
PCB E259-1 (without components) E211747-1 1 X
Screw (+) 3X8 ZMC-3 1 X
