Casio CE-2400 Service Manual

— 29 —
1. Main PCB ass'y
Item Code No. Parts Name Specification Version Q R
MAIN PCB ASS'Y
6193 3602 Main PCB ass'y (E259-1) E211743*2 1 A
IC11 2006 1235 LSI LC36256AL70/85/10 1 A
IC5 2006 1606 LSI UPD75517GF-400-3B9 1 A
IC13 2101 0189 MOS IC TC74HC138AP 1 A
IC10 2105 1071 C-MOS IC TC74HC174AP 1 A
IC4 2114 1512 Liner IC BA10393 1 A
IC7,8,9 2114 2436 Monolythic IC BA12003 3 A
IC2 2120 6741 Monolythic IC BA12004 1 A
IC1 2120 6823 Liner IC LM2575T-5.0/LB03 1 A
IC6 2120 6824 Monolythic IC STA471A 1 A
IC12 2120 7381 Reset IC S-80730AN-Z 1 A
IC3 2120 9181 Monolythic IC BA12001 1 A
Q7,11,13,15,17 2210 7309 Transistor 2SB1240V2-Q,R 5 B
Q2,3 2220 3746 Transistor 2SC4640(T,U)-AC 2 B
Q8,18 2230 4135 Transistor 2SD1853-AA 2 B
Q1 2230 5336 Transistor 2SD1196 1 B
Q6 2250 1099 Digital transistor DTC113ZS-TP-T 1 B
Q9,10,12 2259 0063 Digital transistor DTC114YS-TP-T 5 B
D1~4,10 2301 0089 Diode 1SR35-100A-T-82-T 7 C
D7,9,11~26 2301 0101 Diode 1S2473-T-77-T 26 C
ZD3 2310 6728 Zener Diode RD16EB3-TN-T 1 B
ZD4,5 2310 7229 Zener Diode RD24EB2-TN-T 2 B
ZD2 2310 9449 Zener Diode RD7.5EB3-TN-T 1 B
DA1 2310 9450 Shottky barrier diode SB007W03S-AC 1 B
D8 2310 9452 Shottky barrier diode RK-14V 1 B
X1 2520 3445 Crystal oscillator C-002RX(M90-76) 1 A
R45~50 Carbon film resistor CR-25-1OHMJ-T 6 X
R16~19 Carbon film resistor CR-25-100OHMJ-T 4 X
R73 Carbon film resistor CR-25-150OHMJ-T 1 X
R40 Carbon film resistor CR-25-560OHMJ-T 1 X
R12 Carbon film resistor CR-25-1KOHMJ-T 4 X
R10 Carbon film resistor CR-25-1KOHMG-T 1 X
R26 Carbon film resistor CR-25-1.5KOHMJ-T 1 X
R41,43 Carbon film resistor CR-25-2KOHMJ-T 2 X
R13 Carbon film resistor CR-25-2.7KOHMJ-T 1 X
R30,32~35 Carbon film resistor CR-25-3.9KOHMJ-T 8 X
R55~66 Carbon film resistor CR-25-4.7KOHMJ-T 12 X
R8 Carbon film resistor CR-25-5.1KOHMJ-T 1 X
R39 Carbon film resistor CR-25-6.2KOHMJ-T 1 X
R69 Carbon film resistor CR-25-8.2KOHMJ-T 1 X
R11,15,20~24 Carbon film resistor CR-25-10KOHMJ-T 17 X
R6 Carbon film resistor CR-25-22KOHMG-T 1 X
R27,70,71,79 Carbon film resistor CR-25-56KOHMJ-T 4 X
R14,72 Carbon film resistor CR-25-100KOHMJ-T 2 X
R38 Carbon film resistor CR-25-330KOHMJ-T 1 X
R54 Carbon film resistor CR-25-1MOHMJ-T 1 X
R9 Carbon film resistor R50XT-08J3R9 1 X
R7 Carbon film resistor R50XT-08J122 1 X
R42 Carbon film resistor CR-25-16KOHM-J-T 1 X
R5 Metal film resistor CRH200-FH24-J-301 1 X
R67 Metal film resistor CRH100-FH11-J-6R8 1 X
