Note1: For details about the relationship between the MSB value and the tone, see the Tone List that comes with the
Instrument.
Transmit Sent when a tone setup number is selected.
Receive Receipt causes a change in the tone bank number stored in Instrument memory, but the
tone is not actually changed until a Program Change message is received. For details, see “8 Program
Change”. If LSB is specified as 40H, the type of reverb, chorus, and delay will change according to the
tone when the tone is changed in the Program Change message.
7.2 Modulation wheel or lever (01H)
Message Format: BnH 01H vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when the knob is operated by setting.
Receive Receipt adds, to the tone being sounded, modulation of a depth specified by the value. In
the case of a tone that already has modulation applied, receipt of this message increases the modulation
depth. The modulation effect differs according to the tone being used.
7.3 Portamento Time (05H)
Message Format: BnH 05H vvH
n: MIDI Channel Number
vv: Value
Transmit Sent when portament time is used. Sent when the knob is operated by setting.
Receive Receipt changes the portamento application time.
7.4 Data Entry (06H,26H)
Message Format: BnH 06H mmH (MSB)
BnH 26H llH (LSB)
n: MIDI Channel Number
mm: MSB Value
ll: LSB Value
Transmit Sent when there is a change to the parameter assigned to RPN, NRPN.
Receive Receipt changes the parameter assigned to RPN, NRPN.
8
