CTK-4200
– 17 –
C-2. Undo 26 screws and then remove the BACK-LIGHT-UNIT, LCD components and rubber keys.
NOTE: There are two types of screws. Be sure to use the correct screw when reassembling.
BACK-LIGHT-UNIT
LCD components
BACK-LIGHT-UNIT
