Casio CTK-4200 Service Manual

CTK-4200
– 23 –

TEST ITEMS
Pressing a test button after the diagnostic program was launched or while on the main screen enables
the corresponding test item to be tested.
Test Items Buttons Note
A. BUTTON CHECK 1
B. AC ADAPTOR CHECK 3 AC apaptor
C. ROM CHECK 5
D. RAM CHECK 6
E. ROM VERSION & MODEL CHECK 9
F. LCD CHECK 2
G. PEDAL CHECK RHYTHM Pedal (SP-3 or SP-20)
H. USB CHECK PC, USB cable
<Test Mode Main Screen>

TEST PROCEDURES
A. BUTTON CHECK
A-1. Press the “1” button to select the “BUTTON CHECK”.

Casio CTK-4200 Specifications

General

MIDI-keyboard number of keys	- keys
Interface	USB
Dimensions (WxDxH)	648 x 350 x 102 mm
Product color	Black, Silver

Weight and Dimensions

Weight	4599 g
