Casio CTK-4200 Service Manual

CTK-4200
– 33 –
1: CTK-4200_DI
2: CTK-4200_EU
3: CTK-4200_UK
4: CTK-4200_US
1234
MAIN PCB
N 1 10402681 PCB UNIT/MAIN TK-RJM511401*001 1111 AMDA1
CN8 10236624 CONNECTOR/USB UBR24-4K5G00 1111 C
J1 10206815 JACK/SUSTAIN JY-6314*01-030 1111 C
D4 10009218 DIODE 1SS400TE61 1111 X
IC5 10211950 IC NJM2068M-D(TE1) 1111 X
N IC6 10398240 IC XC6402FV36PR-G 1111 X
L11 10193074 COIL DLW21HN181SQ2L 1111 X
LSI4 10256784 LSI/MEMORY CY62146EV30LL45ZST 1111 C
N LSI3 10396648 LSI/MEMORY MX29GL128ELT2I-90G 1111 C
N Q12,Q13 10399706 TRANSISTOR DSC500100L 2222 X
X1 10375016 RESONATOR 7V48080006 1111 X
KEYBOARD PCB
2 10313200 PCB UNIT/KYA TK-RJM508618*002 1111 CKYA1/KYA2
D1-D61 10294400 DIODE LM1MA142WKT1G 61 61 61 61 X
BACK LIGHT UNIT (including amp, power and console circuit)
N 3 10402680 BACK LIGHT UNIT TK-RJM511354*001 1111 X
IC3,IC4 10206677 IC NJM2068D-D 2222 X
IC2 10300598 IC TA8227APL-D12-H-T 1111 X
IC5 10222381 LSI ST7066U-0A-QG 1111 C
IC1 10159709 LSI UPD65881GK-1019ETA 1111 C
J2 35015103 JACK/DC HEC3110-01-010 1111 A
J1 10305218 JACK/PHONE JY-6316B*01-070 1111 B
J3 10305131 JACK/AUDIO IN ST-3529B 1111 B
L2,L5 10231919 COIL RB53-856396NP 2222 X
L1,L3,L4 10231920 COIL RB53-856397NP 3333 X
Q7 10206835 TRANSISTOR KTA1046-Y-U/P 1111 X
N VR3 10407264 VARIABLE RESISTOR F164KPD-1N-CASIO-3 1111 BMain volume
X1 10093909 RESONATOR CSBLA1M00J58-B0 1111 X
D3,D5 23901820 DIODE 1SS355TE-17 2222 X
D1,D2 10261170 DIODE SRT14-A2 2222 X
D4 23603102 DIODE UDZSTE-175.1B 1111 X
N
Q2,Q3,Q5,
Q6,Q9
10399706 TRANSISTOR DSC500100L 5555 X
Q1 10217742 TRANSISTOR KTA1270-Y-AT/P 1111 X
Q4 10206675 TRANSISTOR KTA1273-Y-AT/P 1111 X
4 10308432 LED SLR343BD2T3F 2222 X
5 10131110 REFLECTOR RJM502577-001V01 1111 X
6 10248119 BACK LIGHT PLATE RJM506818-001V01 1111 X
7 10250780 FILM RJM507061-001V01 1111 X
8 10131094 TOP PIECE RJM502565-001V01 1111 X
9 10270485 SPONGE/8X75 M441167-001V01 1111 X
PANEL UNIT
N 10 10402929 LCD ZAS-TY012723DN00 1111 X
11 10203058 RUBBER CONNECTOR/for LCD RJM505822-001V01 2222 X
N 12 10402055 DISPLAY PLATE RJM511149-001V01 1111 X
N 13 10402614 KNOB/ROTARY RJM502503-025V03 1111 C
14 10214317 DOUBLE FACED TAPE/6X10 RJM506386-001V01 1111 X
15 10136565 PACKING/8X510 M441190-002V01 1111 X
N 16 10402629 CASE/PANEL RJM511111-001V01 1111 X
N 17 69265720 FABRIC TAPE/5X30 M440583-1
5555 X
N 18 10113739 FABRIC TAPE/5.5X22 RJM502452-001V01 3333 X
19 10305409 SHEET/V-ZERO RJM508951-001V01 2222 X
20 10270485 SPONGE/8X75 M441167-001V01 1111 X
21 10263728 PACKING M441117-001V02 1111 X
Specification R RemarksN Item Code No. Parts Name
Price
Code
Q'ty
