Casio CTK-4200 Service Manual

CTK-4200
– 34 –
1: CTK-4200_DI
2: CTK-4200_EU
3: CTK-4200_UK
4: CTK-4200_US
1234
Specification R RemarksN Item Code No. Parts Name
Price
Code
Q'ty
N 22 10402632 RUBBER BUTTON/A RJM511139-001V01 1111 X
N 23 10402634 RUBBER BUTTON/B RJM511140-001V01 1111 X
N 24 10402636 RUBBER BUTTON/C RJM511141-001V01 1111 X
N 25 10402638 RUBBER BUTTON/D RJM511142-001V01 1111 X
N 26 10402640 RUBBER BUTTON/E RJM511143-001V01 1111 X
N 27 10402642 RUBBER BUTTON/F RJM511144-001V01 1111 X
N 28 10402644 RUBBER BUTTON/G RJM511145-001V01 1111 X
SIDE PANEL UNIT
N 29 10402648 SPEAKER COVER UNIT/LEFT RJM511355*001 1111 X
N 30 10402650 SPEAKER COVER UNIT/RIGHT RJM511356*001 1111 X
N 31 10190385 FABRIC TAPE/12X30 RJM504470-002V01 8888 X
N 32 10402626 CASE/SIDE PANEL/LEFT RJM511039-001V01 1111 X
N 33 10402627 CASE/SIDE PANEL/RIGHT RJM511040-001V01 1111 X
34 69196290 FABRIC TAPE/20X10 M411742-001 2222 X
35 10405274 PACKING/8X200 RJM511196-002V01 2222 X
36 10272063 SPEAKER C12J03 2222 X
N 37 10402600 WIRE/WHITE 1007TASC24350W3030 1111 Xfor Left speaker (+)
N 38 10402599 WIRE/GREEN 1007TASC24350G3030 1111 Xfor Left speaker (-)
N 39 10377007 WIRE/BLUE 1007TASC24850B3030 1111 Xfor Right speaker (+)
N 40 10377008 WIRE/BROWN 1007TASC24850T3030 1111 Xfor Right speaker (-)
N 41 69265830 SPONGE/35X260 M440589-1 2222 Xfor Speaker wires
KEYBOARD UNIT
42 10399802 WHITE KEY/CB RJM507243*004V03 4444 A
43 10399803 WHITE KEY/CS RJM507244*004V03 1111 B
44 10289646 BLACK KEY/10p RJM506595-005V02 2222 A
45 10289647 BLACK KEY/5p RJM506595-006V02 1111 B
46 10269451 RUBBER CONTACT/CB RJM507656-001V01 4444 A
47 10270393 RUBBER CONTACT/CS RJM507657-001V01 1111 B
MAIN CASE UNIT
N 48 10402679 CASE UNIT/MAIN TK-RJM511358*001 1111 X
49 10284332 BRACKET/for STAND M440866-001V02 2222 X
50 69226920 RUBBER FOOT M41361-6 4444 X
N 51 10373683 FELT/LOWER LIMIT/KEYBOARD RJM508593-001V02 1111 X
52 10317116 FELT/DAMPER/KEYBOARD RJM509138-001V01 1111 X
N 53 10373681 FELT/UPPER LIMIT/KEYBOARD M440342-001V03 1111 X
N 54 10400576 BATTERY TERMINAL/+ RJM511046-001 1111 X
N 55 10380432 BATTERY TERMINAL/- M440002-001V03 1111 X
56 69271060 BATTERY TERMINAL/A M440676-1 2222 X
57 69271070 BATTERY TERMINAL/B M440677-1 3333 X
58 10286819 BATTERY COVER TK-M340884*027 1111 X
59 10214396 PACKING/7X180 RJM506032-001V01 2222 X
N 60 69307179 SPONGE/30X35 M441046-1 1111 X
N 61 10381069 LOWER COVER/A RJM508655-001V04 1111 X
N 62 10381070 LOWER COVER/B RJM508656-001V04 1111 X
N 63 10381071 LOWER COVER/C RJM508657-001V04 1111 X
ACCESSORIES
- 10025472 MUSIC STAND M141071-1 1111 C
N - 10399696 AC ADAPTOR AD-E95100LG-P2 1 B
N - 10408260 AC ADAPTOR AD-E95100LU-P2 1 B

Casio CTK-4200 Specifications

General

MIDI-keyboard number of keys	- keys
Interface	USB
Dimensions (WxDxH)	648 x 350 x 102 mm
Product color	Black, Silver

Weight and Dimensions

Weight	4599 g
