Casio CTK-691 - 30 User Instrument Parameter Set; 31 User Wave Parameter Set

To Next Page

To Previous Page

30 User Instrument Parameter Set

This is the parameter set that is associated with and sent with Drum.

All key numbers are supported, so one drum set is associated with 128 instruments.

System Exclusive Format

31 User Wave Parameter Set

This is the parameter set that is associated with and sent with Voice or Instrument.

16 waves are associated with Voice, and one wave with Instrument.

System Exclusive Format

Field Value

01 SYSEX F0

02 MAN 44

03 MOD 11,02

04 dev Either 00 to 1F, or 7F

05 act 04(HDS), 05(HDR), 07(Control)

06 cat Instrument = 06

07 prm 00-7F

08 ilen/dlen See "IV This Model's System Exclusive Messages".

09 ps Indicates this Model's number being transferred.

For details, see "38 About Parameter Set (PS) numbers".

10 index See "IV This Model's System Exclusive Messages".

11 data See "IV This Model's System Exclusive Messages".

12 sum See "IV This Model's System Exclusive Messages".

13 EOX F7
