Casio CTK-691 - 41 Setting Value Table; Off;On Setting Value Table; Slow;Fast Setting Value Table; Rotate;Break Setting Value Table

74
Part VIII
Setting Values and
Send/Receive Values
41 Setting Value Table
41.1 Off/On Setting Value Table
41.2 Slow/Fast Setting Value Table
41.3 Rotate/Break Setting Value Table
41.4 -24 to 0 to 24 Setting Value Table
41.5 -64 to 0 to 63 Setting Value Table
41.6 Pan Setting Value Table
41.7 -99 to 0 to 99 Setting Value Table
41.8 Type 0 to Type 7 Setting
Value Table
41.9 Master EQ Type Setting
Value Table
Value Transmit Receive
Off 00H 00H-3FH
On 7FH 40H-7FH
Value Transmit Receive
Slow 00H 00H-3FH
Fast 7FH 40H-7FH
Value Transmit Receive
Rotate 00H 00H-3FH
Break 7FH 40H-7FH
Value Transmit/Receive
-24 28H
::
0 40H
::
24 58H
Value Transmit/Receive
-64 00H
-63 01H
::
0 40H
::
62 7EH
63 7FH
Value Transmit/Receive
Left 00H
::
Center 40H
::
Right 7FH
Value Transmit/Receive
(MSB-LSB)
-99 00H-40H
::
0 40H-00H
::
99 7FH-00H
Value Transmit Receive
Type0 00H 00H-0FH
Type1 10H 10H-1FH
Type2 20H 20H-2FH
Type3 30H 30H-3FH
Type4 40H 40H-4FH
Type5 50H 50H-5FH
Type6 60H 60H-6FH
Type7 70H 70H-7FH
Value Transmit/Receive
Standard 00H
Bass + 01H
Treble + 02H
Loudness 03H
Mellow 04H
Bright 05H
Rock 06H
Dance 07H
Jazz 08H
Classic 09H
