Specifications
E-86
* The same memory area is used to store waveform data, accompaniment data, and SMF data.
Mixer Function
 Channels:
 Parameters:
16
Tone; part on/off; volume; pan pot; octave shift; coarse tune; fine tune; reverb send;
chorus send; DSP line; DSP level; DSP pan; DSP system reverb send; DSP system
chorus send
MIDI: 16 multi-timbre receive, GM Level 1 standard
Other Functions
 Transpose:
 Tuning:
 LCD:
49 steps (–24 semitones to +24 semitones)
Variable (A4 = approximately 440Hz ±100 cents)
Adjustable contrast
SMF Player Flash memory storage for up to 200 files*
 Supported Format: SMF0
Flash Memory Capacity: 2MB
Shared Area: Approximately 1.5MB (waveform data, accompaniment data, SMF data)
 Further storage of waveform, accompaniment, and SMF data becomes impossible
after the total of such data reaches approximately 1.5MB.
Terminals
 MIDI Terminals:
 Sustain/Assignable Terminal:
 Headphone/Output Terminal:
 Power Supply Terminal:
IN, OUT
Standard jack (sustain, sostenuto, soft, rhythm start/stop)
Stereo standard jack
Output Impedance: 140Ω
Output Voltage: 4.5V (RMS) MAX
9V DC
Power Supply:
 Batteries:
 Battery Life:
 AC Adaptor:
 Auto Power Off:
Dual power supply system
6 D-size batteries
Approximately 4 hours continuous operation on manganese batteries
AD-5
Turns power off approximately six minutes after last key operation. Enabled under
battery power only, can be disabled manually.
Speaker Output: 3W + 3W
Power consumption: 9V 7.7W
Dimensions: 96.0 x 37.5 x 14.6 cm (37
13
/
16
x 14
3
/
4
x 5
3
/
4
inch)
Weight: Approximately 5.6 kg (12.3lbs) (without batteries)
