Casio DT-X200-10E Hardware Manual

DT-X200 Hardware Manual P.13
Item Specification Remark
WLAN Standard IEEE 802.11a/b/g/n
Radio type Spread Spectrum
Modulation type
802.11a/g/n:
OFDM(OrthogonalFrequencyDivisionMultiplexing）
802.11b:
DSSS(Direct Sequence Spread Spectrum)
BPSK,QPSK,CCK,16QAM,64QAM
Emission Designation
802.11a/g/n：D1D, G1D
802.11b：G1D
Frequency
＜Center frequency＞
IEEE802.11a/n
W52:36/40/44/48ch(5.18 to 5.24GHz)
W53:52/56/60/64ch(5.26 to 5.32GHz)
W56:100/104/108/112/116/120/124/128/132/136/140ch
(5.50 to 5.70GHz)
IEEE802.11b
1 to 13ch(2.412 to 2.472Ghz)
IEEE802.11g/n
1 to 13ch(2.412 to 2.472Ghz)
＜Frequency range＞
IEEE802.11a/n
5.15 to 5.35GHz(W52,W53)
5.47 to 5.725GH z(W56)
IEEE802.11b
2.400 to 2.497GHz
IEEE802.11g/n
2.400 to 2.4835GHz
Baud rate
802.11a/g : 54Mbps (maximum)
802.11b : 11Mbps (maximum)
802.11n : 65Mb
p
s
(
maximum
)
Communication range
802.11b/g/n : Approx.50m(indoor), Approx.150m(outdoor)
802.11a/n : A
pp
rox.50m
(
indoor
)
, A
pp
rox.150m
(
outdoor
)
Number of channels
802.11a/n：W52:4,W53:4,W56 : 11 (11n is 5GHz range)
802.11b : 13
802.11
g
/n : 13
(
11n is 2.4GHz ran
g
e）
Channel spacing
802.11a/n : 20MHz (11n is 5GHz range)
802.11b/
g
/n : 5MHz
(
11n is 2.4GHz ran
g
e）
Channel band width 802.11a/b/g/n： 20MHz
Other feature Roaming among Access-Points
Output power
802.11a : 14dBm (maximum)
802.11b : 20dBm (maximum)
802.11g : 15dBm (maximum)
802.11n : 14dBm (maximum)
Security WEP(64/128bit), WPA, WPA2
WPA encrypted method TKIP, AES
Authorize method PSK, EAP-TLS, PEAP-MSCHAP-V2
CAS
IO COMPUTER CO., LTD.
