Casio DT-X5M10E User Manual

— 72 —
Notes: 1. The numbers in the item column correspond to the same numbers in exploded view.
2. MARKS:
Q:Quantity used per unit
R:Rank A: Essential
B: Stock recommended
C: Less recommended
X: No stock recommended
BACK CASE BLOCK
M10E M10R
16 1017 4727 CASE ASSY/BACK 39-W791B-011 1 1 CO C
17 1017 4724 BUTTON/RESET 42-W7914-020 1 1 AA X
18 1017 4723 RUBBER/RESET 47-W7914-010 1 1 AA X
19 1017 4722 BUZZER ASSY 77-W7918-003 1 1 BD C
20 1017 4721 COVER/BUZZER 47-W791B-060 1 1 AA X
21 1017 4725 SUPPLY ASSY 42-W791B-101 1 1 CE B
22 1017 4726 STOPPER/SUPPLY MODULE 42-W791B-080 1 1 AB X
23 1017 4738 SPONGE 47-0019A-200 1 1 AF X
24 1017 4719 PCB ASSY/BRIDGE 77-W7917-003-1 1 1 CO B
25 1017 4720 CABLE/FFC 43-W791S-010 1 1 AF B
26 1017 4737 COVER/MAINTENANCE PORT 42-W791B-070 1 1 AB X
27 1017 4736 SPONGE 47-W7918-010 1 1 AA X
28 1017 4729 BATTERY BOX 42-W791M-101 1 BA C
29 1017 4731 COVER/BATTERY 42-W791M-401 1 1 AF C
30 1017 4730 COVER/LARGE BATTERY 42-W791M-201 1 1 AF C
31 1017 4732 SCREW/M2.5*6L 35-01125-6R0-1 2 2 AA X
32
10174728
1017 4718
SCREW/TAP T2*6L
SCREW/TAP T2*4L
35-01120-6RB
35-C1120-4R0
4 4 AA X
33 1017 4718 SCREW/TAP T2*4L 35-C1120-4R0 3 3 AA X
1017 8338 LABEL/RATING EE 45-W7913-050 1 AD
1017 8339 LABEL/RATING ME 45-W7913-040 1 AD
Item #16 CASE ASSY/BACK contains the following Items.
16-1 1017 4763 FILTER/IR 47-W791R-010 1 1 AS C
16-2 1017 4766 FILTER/LASER 47-W791B-030 1 1 AX C
16-3 1017 4768 BUTTON/TRIGGER 42-W791B-030 2 2 AC X
16-4 1017 4765 RUBBER/TRIGGER 47-W791B-040 2 2 AA B
16-5 1017 4767 FPC/TRIGGER 43-W7917-020 1 1 BN C
16-6 1017 4769 SLIDE/BATT LOCK L 42-W791B-020 1 1 AC C
16-7 1017 4771 COVER/BATT LOCK L 42-W791M-020 1 1 AD X
16-8 1017 4770 SLIDE/BATT LOCK R 42-W791B-010 1 1 AC C
16-9 1017 4772 COVER/BATT LOCK R 42-W791M-010 1 1 AD X
16-10 1017 4773 SCREW 35-00120-5RB 4 4 AA X
16-11 1017 4764 RUBBER/BATT 47-W791M-010 1 1 AH X
Item #21 SUPPLY ASSY contains the following Item.
21-1 1017 4762 TAPE 47-W791S-020 2 2 AA C
Quantity
Price
Code
R
34 X
Item # Part No. Part Name Descriptions
